PP PC ABS Handheld Riveting Welder / Ultrasonic Riveting Welder For Automotive Interior Parts

PP PC ABS Handheld Riveting Welder / Ultrasonic Riveting Welder For Automotive Interior Parts

Specifications:

Description:

Independent research and development on power hand-held ultrasonic spot welding machine with 28K, 35K, 30K three different frequencies. Can be different for the following purposes;
Ultrasonic welding: ultrasonic vibration with ultrasonic welding mould, the ultrasonic welding energy conduction to the plastic surface, resulting in local temperature, so that the plastic surface melting. Under the pressure of the ultrasonic hand, so to weld plastic, beautiful, strong effect.

Competitive Advantages in Auto Industry:

• 1. application in riveting, forming and welding
• 2. light weight, easy to take, easy to operate (handheld)
• 3. Equipped with welding timer
• 4. Easty to set time welding
• 5. Equipped with an overload protection circuit( Voltage, current, phase, temperature, output)
• 6. FET power output
• 7. Automatic resonance
• 8. Maintain the amplitude function automatically
• 9. Starting: achieving maximum power with 105msec

Portable Ultrasonic Sounproof Spot Welder Principle:

When the ultrasonic role in the thermoplastic plastic contact surface, it will generate tens of thousands of times per second, high frequency vibration, this high-frequency vibration, ultrasonic energy through the ultrasonic wave transmitted to the mold to ultrasonic welding material surface, it will produce high-temperature materials. Plastic contact surface resulting in rapid melting, coupled with stress, it blend and coagulation, so that to achieve the purpose of ultrasonic welding.

Applications In Automobile:

Ultrasonic Spot Welding is mainly used in automotive interior parts. Ultrasonic spot welding in sound-proof cotton of engine cover, trunk and wheel casing, and hallstand felt. Ultrasonic Riveting Welding can be used in automobile air-conditioning outlet welding, car rear view mirror, car door handles, hand car door and so on.Automotive plastic parts are mostly welded in non-standard ultrasonic welding equipment, long multi-station design, with PCL program control and LCD operation, large automotive complex workpiece welding, including different directions of the welding surface, in multiple locations.

PP PC ABS Handheld Riveting Welder / Ultrasonic Riveting Welder For Automotive Interior Parts
