Consumer Industry Ultrasonic Geometry Welding Tightness Mark-free Surface
Description:
The HS-X20P series of ultrasonic welder offer a compact design to conserve work space,and is easy for operation and maintenance to achieve an outstanding cost-performance.
The HS-X20P series of ultrasonic welder is using a mechanical control and accurate duplication of welder parameters setting design for a more stable and reliable weld performance, suitable for more industrial applications.
Technical Parameters:
| Item No | HS-X20P |
| Frequency | 20Khz |
| Power | 1500W |
| Voltage | 200-240V, Alternating current |
| 50-60hz, Single phase |
| Electric current | 10A |
| Range of welding time | 0.05-10/sec |
| Environment Temperature | 5-50℃ |
| Air supply requirements | Clean dry compressed air, maximum pressure 7kg |
| Maximum pressure | 1.96KN |
| Maximum stroke | 100MM |
| Beats | 80CPM |
| Operated mode | Time mode or Energy mode |
| Weight | 110Kgs |
Consumer industry applications:
Using ultrasonics, consumer components can be produced and joined in a cost-effective way; at the same time, the process provides great flexibility in terms of design. High requirements for visual appearance, production speed, or geometry are met.
- Light-weight and robust
- 100% tightness
- Mark-free surfaces
Principle:
Transmitted ultrasonic energy through welding parts to welding area, local high temperature will happen due to high acoustic resistance between two welding interface places. Also, no enough time dissipating out heating energy timely because of poor plastic thermal conductivity, heating energy gathered in welding area since could not dissipating out timely, the two plastic contact areas will welt rapidly, coupled with a certain pressure, it makes fusion to one unite. When ultrasonic stop function, and keep the pressure sustain to make its solidification molding, finally forming a strong molecular chain, which achieve the purpose of welding. And the welding strength can close to raw material body strength.
Main advantages:
- High Amplitude to adjusting different plastic material welding.
- Exclusive system protection monitor module.
- Self test and automatic frequency search.
- Dynamic Triggering to provide consistent welding result
Other Applications for Ultrasonic Welding
INSERTING
Threaded inserts, grub screws or other parts can be ultrasonically embedded in thermoplastics.
STAKING
Melting and forming of a plastic stud to retain or lock another material, often dissimilar, in place.
SPOT WELDING
Used for joining two thermoplastic parts with no pre-formed hole or energy director. This technique is particularly suited to large parts or parts with complicated geometry and thermoformed or blow-molded parts without a joint.
SWAGING
Used to capture another component of an assembly by melting and reforming a ridge of plastic around the component. The ridge locks the second component in place without welding the materials together.
Consumer Industry Ultrasonic Geometry Welding Tightness Mark-free Surface
Workshop:
CE Certification:
Packing&Shipping:
Shipping Port:Shanghai
Shipping Term:By express,by air,by ocean and so on.
Leading Time:Quick production leading time and fast delivery.Usually 1-3days if we have in stock.
Payment:
Quality control:
3 times old test to confirm the products is well quality.
20 technician work together , and learn together , to improve our products.
48 hours working time to test the stability of our product before sending out.
