Non-woven tote bag/handbag/carry bag spot welding equipment by ultrasound
Description:
By using high-frequency, the sound wave is transmitted from the welding head to the welding surface of the workpiece, and the working object molecules are instantaneously rubbed to reach the melting point of the plastic, thereby completing the rapid dissolution of the solid material and completing the welding.
The joint strength is as strong as the piece of continuous material, and as long as the joint faces of the product are well designed, the welding could achieve completely sealed. The special alloy steel can be used to make the flower wheel mold, and various complicated flower-shaped patterns can be developed according to customers' requirements.
The welding head is wear-resistant and has a long service life, the flower mold is easy to assemble and disassemble, the eccentric adjustment is flexible, and the level is high.
| Frequency | 35k | 28k | 28k | 20k | 28k | 28k | 28k |
| Power | 700 | 300&500 | 400&700 | 900 | 300&500 | 400&700 | 500&800 |
| Horn | ≤10mm | ≤10mm | ≤12mm | ≤1m | ≤8mm | ≤12mm | ≤12mm |
| Housing Diameter | 51mm | 64mm | 40mm | 45mm | 60mm |
| Handle Size | 100mm×45mm×32mm | —— | —— | —— |
| Weight Without Wire and Horn | 0.6kg | 1.3kg | 1.3kg | 1.5kg | 0.6kg | 0.6kg | 1.3kg |
| Digital generator | ● | ● | ● | ● | — | ● | ● |
| Analog generator | ● | ● | ● | ● | ● | ● | ● |
Competitive Advantage:
1. Rapid sonotrode exchange
2. High quality, heavy duty aluminum housing
3. High frequency and control cable to the ultrasound generator are in a strong and highly flexible braided plastic sheet
4. Timer-controlled air cooling as an option
Applications:
Ultrasonic non-woven bag welding machine is suitable for all kinds of non-woven fabrics, chemical fiber, plastic and composite materials. It is widely used in advertising bags, handbags, gift bags, shopping bags, high-quality non-woven bags, laminated non-woven bags. Processing of inner and outer packaging bodies of various products such as color printing woven bags, red wine bags and beach seats. Non-woven green shopping bags (widely suitable for shopping malls, department stores, supermarkets, green shopping bags); non-woven suit dust cover, non-woven wardrobe, non-woven storage bag, wild dining non-woven cloth apron and sleeve Set, non-woven clothing bags; hotel supplies or home travel supplies: disposable slippers, beach shoes, sauna bathrobes, briefs, laundry bags, newspaper bags, shoe bags, tea trays and other non-woven environmentally friendly products.
